Semi Automatic Piston Paste Filling Machine 1000ML
A pure experience – Get to know our semi-automatic machine.
10 ML to 1000 ML
Filling Range
0.5 +/-
Filling Accuracy
8-9 Bottles
Filling Speed Per Min.
SS-304
Machine Construction
A semi-automatic piston paste filling machine is a versatile piece of equipment designed to accurately dispense viscous substances such as pastes, ketchup, types of oils, gels, cosmetic creams, pharmaceutical paste, sauces, cleaning paste and many more types of pastes into containers. Operated semi-automatically, it typically involves manual placement of containers under the filling nozzle and activation of the filling process, while the machine automatically dispenses the desired amount of product using a piston-driven mechanism. These machines are widely used in industries such as food, cosmetics, pharmaceuticals, chemicals, personal care, home care, automotive and many more for filling various types of containers including jars, bottles, tubes, and pouches. With adjustable filling volumes and precise control mechanisms, semi-automatic piston paste filling machines ensure consistent and reliable filling, enhancing efficiency and productivity in packaging operations.
Suitable Products for These Machines

Ketchup

Pharmaceutical Paste

Facewash

Cosmetic Creams

Toothpaste

Cooking oils
And Many More Products

Full Specification And Model Details
PARTICULAR |
SEMI AUTOMATIC PISTON PASTE FILLING MACHINE 1000ML |
FILLING RANGE | 10 ML – 1000 ML |
AIR PRESSURE | 0.4 – 0.6 MPA |
FILLING SPEED | 08 – 09 BOTTLES/MIN |
FILLING ACCURACY | 0.5 + /- |
CONTROL MODE | MANUAL / AUTO |
HOPPER CAPACITY | 30 KG AS PER PRODUCT |
MACHINE CONSTRUCTION | SS-304 |
POWER SUPPLY | 230V /50 Hz |
K.W | 300 W |
MACHINE WEIGHT | Approx 22.00 KG |
Frequently Asked Questions (F.A.Q.s)
1. Does this machine have easy maintenance?
-
Yes, the machine is easy to clean and maintain. Parts that come in contact with the product can be easily disassembled and cleaned.
2. Is it possible to adjust the time gap between filling two containers, either for increasing or decreasing it?
-
Yes, the machine have flexibility to adjust the time gap for filling the paste according to the specific needs.
3. What is the storage capacity of the hopper in this machine?
- The hopper of the machine can hold up to 35 kg.
4. What safety feature does this machine comes with?
- The machine has the safety feature of emergency stop button.
5. Is there any provision for a dual-nozzle setup?
-
Yes, the machine has dual-nozzle provision for higher output and efficiency.
